Kestrel 1000 Wind Meter / Anemometer

Out of stock
SKU: 0810
500.00 SR

Use this text to encourage communication or promote sharing on social networks.

You can also add links

The Kestrel 1000 handheld wind speed meter (anemometer) is a simple, reliable and extremely accurate air velocity measurement device delivering current, average and maximum wind speed readings, you can easily change between mph, km/h, ft/min, m/s, knots and Beaufort. This is the meter of choice for crane operators and water sports enthusiasts alike.


Features

  •  Simple 3-Button Control

  •  Large easily read LCD display with backlight

  •  Standard user-replaceable CR2032 Coin Cell Battery (Average Life 300 Hours)

  •  Data Hold Function • Drop-Tested (MIL-STD-810F)

  •  Certificate of Conformity

  •  Neck Lanyard

  •  Patented Impeller and Sensor Technology (user-replaceable)

  •  Slip-On/Off Protective Cover

  •  Time of Day

  •  Waterproof & Floats

  •  5 Year Warranty

    Specification

    Primary Measurement Units Resolution Accuracy (+/-) Range: Max Operational Specification (if less) Notes
    Wind Speed or Air Velocity m/s 0.1 Larger of 3% of reading, least significant digit or 20 ft/min 0.6 to 60.0 m/s 0.6 to 40.0 m/s 1 inch diameter impeller with precision axle and low-friction Zytel® bearings. Start-up speed stated as lower limit, readings may be taken down to 0.4 m/s | 79 ft/min | 1.5 km/h | .9 mph | .8 kt after impeller start-up. Off-axis accuracy -1% @ 5° off-axis; -2% @ 10° -3% @ 15°. Calibration drift < 1% after 100 hours use at 16 MPH | 7 m/s. Replacement impeller (NK PN-0801) field installs without tools (US Patent 5,783,753).
    ft/min 1 18 to 11,811 ft/min 118 to 7,874 ft/min
    km/h 0.1 2.2 to 216.0 km/h 2.2 to 144.0 km/h
    mph 0.1 1.3 to 134.2 mph 1.3 to 89.5 mph
    knots 0.1 1.2 to 116.6 knots 1.2 to 77.8 knots
    Beaufort 1 0 to 12 B
    Max/Avg Wind One-button clear and restart of Max Wind Gust and Average Wind measurement by powering down and restarting unit.
    Display & Backlight Reflective 3 1/2 digit LCD. Digit height 0.36 in / 9 mm. Aviation green electroluminescent backlight (except in Kestrel 1000). Manual activation with auto-off.
    Response Time & Display Update All measurements except those based on relative humidity respond accurately within 1 second. Relative humidity and all measurements which include RH in their calculation may require as long as 1 minute to fully equilibrate to a large change in the measurement environment. Display updates every 1 second.
    Operational & Storage Temperature Range The operational temperature range of the liquid crystal display and batteries is 14° F to 131° F / -10 °C to 55 °C. Measurements beyond the operational range can be taken by briefly exposing unit to extreme conditions such that the display and batteries remain within the operational range. Storage range -22 °F to 140 °F / -30 °C to 60 °C.
    Auto Shutdown After 45 minutes of no key presses.
    Certifications CE certified, RoHS and WEEE compliant. Individually tested to NIST-traceable standards (written certificate of tests available at additional charge).
    Battery CR2032, one, included. Average life, 300 hours. Battery life reduced by backlight use in 2000 to 3500 models.
    Environmental Waterproof (IP67 and NEMA-6). MIL-STD-810F, Transit Shock, Method 516.5 Procedure IV; unit only; impact may damage replaceable impeller.
    Size & Weight 4.8 x 1.9 x 1.1 in / 12.2 x 4.8 x 2.8 cm, 3.6 oz / 102 g (including slip-on cover).
    Colour Options Blue
