EXTECH DC POWER SUPPLY SINGLE OUTPUT 600W (382276)
Regular price
1,650.00 SR
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
The EXTECH 382276 is a high-performance single output DC power supply designed for laboratory and industrial applications. It provides a stable and adjustable output, making it suitable for a variety of testing and powering needs.
Features
- Output Voltage: Adjustable from 0 to 30V DC.
- Output Current: Adjustable from 0 to 20A.
- Power Rating: Maximum output power of 600 Watts.
- Display: Dual LED displays for easy monitoring of voltage and current.
-
Operating Modes:
- Normal mode for manual control.
- Preset mode with three popular voltage presets (5V, 13.8V, and 25V).
- Set mode for user-customizable presets.
- Remote control mode for external adjustments.
- Protection Features: Includes over-voltage, over-temperature, and short circuit protection.
Specifications
| Specification | Details |
|---|---|
| Model No | 382276 |
| Output Voltage | 0 to 30V DC |
| Output Current | 0 to 20A |
| Maximum Power | 600W |
| Ripple and Noise | <5mVrms |
| Dimensions | 7.9 × 3.5 × 8.5 inches |
| Weight | 5.7 lbs (2.6 kg) |
| Power Supply | 120VAC, 50Hz/60Hz |
| Warranty | 2 years |
